Mainstream EtCO2 Capnography Module Capno-M

A mainstream end-tidal carbon dioxide monitoring sensor, it has a unique sample cell protects internal NDIR components from pollution. Compatible with multiple protocols (Respironics, Phasein, CPT, KM, etc.)

Mainstream EtCO2 Capnography Module Capno-M

Features of Mainstream EtCO2 Capnography Module Capno-M

01.
Plug and play

There is no circuit inside the host, just a serial port.

02.
High Precision

Carefully selected multi-channel narrowband filters and infrared light sources, hardware design and software algorithm, to achieve high signal-to-noise ratio, to ensure the measurement accuracy in the temperature range of 5-50°C and the concentration range of 0-20%.

03.
Low Power Consumption

Suitable for battery-powered use, instant start, accurate data can be obtained within 10 seconds of power-on.

04.
Atmospheric pressure and Interference gas compensation

By receiving the pressure and interfering gas parameters input by the host, the compensation calculation can be automatically performed to ensure the measurement accuracy in a variety of occasions.

05.
OEM Solution

Reliable EtCO2 OEM solutions, multiple communication protocols to make your products quickly upgrade assembly.

Specifications of Mainstream EtCO2 Capnography Module Capno-M

TechniqueNon-dispersive infrared gas analysis, Multi-channel infrared detector, Infrared resource, no moving ports
Storage-40to 70C,<90% RH, non-condensing
Operation5 to 50°℃,10 to 90% RH, non-condensingCircumstance pressure:55-115kP
Power demand5 V+5%(max ripple 200 mVp-p)Power consumption:<150mA
lnterfaceRS-232/ Standard E-8-1,38.4 kBaud,10ms data interval(KM) or customized communication protocol.co2 measurement range: 0-19.7%,150mmHg,or 0-20kPa
co2 resolution0.1mmHg
co2 measurement accuracy41 - 70 mmHg 土 5% of reading
71 - 100 mmHg 土 8% of reading
101 - 150 mmHg  10% of reading
Respiration rate: 2-150 bpm
Respiration rate2-150 bpm
Respiration rate accuracy1% 士1bpm
CompensationN2O, O2, Agent (Host supplied)
Barometric Pressure compensation400 to 860mmHg automatic
Warm-up timeTo reach designed deviation 97% within 8s, toreach designed deviation within 20s
Rise timeAbout 70ms
cO2 StabilityShortly drifting less than 1mmHg,after 4 hours' power on.Longly drifting does not influence nominal accuracy aftercontinuous 140 hours' power on.
CalibrationNo routine user calibration required,
Zero:zero proceeding when replacing adaptor
EtCO2 calcualtionevery breath,10 or 20s averagely
Shock ImpactIEC TR 60721-4-7 Class 7M3,EN60068-2-27 Shock,EN60068-2-64 Random vibration
Regulatory Designed to meet the following standardsIEC 60601-1-2,EN55011 - CISPIR 11 Class B
IEC61000-4-2 Electrostatic Discharge lmmunity,IEC 61000-4-3 Radiated lmmunity,
Designed to comply with 93/42/EEC (MDD CE Marking), FDAStandards, Minimum Performance and Safety Requirementsfor Capnometers ISO80601-2-55


Mainstream Capnography Sensor Capno-M Application Scenarios

  • High signal-to-noise ratio

Capno-M is a mainstream CO2 module.

It is equipped with high-quality Multi-Channel Narrowband Filters, IR Light Source, Well-designed Hardware Circuit and Software Algorithms to achieve gas concentration measurement with high signal-to-noise ratio;

  • Long continuous working time

With the self-developed adapters, they can continuously work for a long time in high temperature environment.

  • Plug-and-play

It can be used in conjunction with a multi-parameter monitor. The monitor only needs one interface, which can be connected to the module for use.

  • Atmospheric pressure compensation

There is an internal atmospheric pressure sensor, which can automatically adjust the atmospheric pressure and suitable for various altitude ranges and harsh environments;

  • OEM solutions

We provide the reliable carbon dioxide OEM solutions, with multiple protocols, so that products can be quickly upgraded and assembled.
