EtCO2 Modules

The end-tidal carbon dioxide modules (etco2 modules) independently developed and produced by Kingst can be used with multi-parameter patient monitors, ventilators and anesthesia machines for monitoring of real-time ETCO2 concentration, inhaled CO2 concentration, respiratory rate, inspiratory and expiratory times.

Types of Capnography EtCO2 Module

Mainstream EtCO2 Capnography Module Capno-M
Mainstream EtCO2 Capnography Module Capno-M
A mainstream end-tidal carbon dioxide monitoring sensor, it has a unique sample cell protects internal NDIR components from pollution.
Sidestream EtCO2 Capnography Module Capno-S
Sidestream EtCO2 Capnography Module Capno-S
A side stream EtCO2 sensor, accurate and durable, suitable for various complex environments.
Mainstream EtCO2 Capnography Module Capno-M+
Mainstream EtCO2 Capnography Module Capno-M+
A product that can be used for both intubated and non-intubated patients, breaking through the limitation that mainstream modules can only be used for intubated patients.
Sidestream EtCO2 Capnography Module Capno-S+
Sidestream EtCO2 Capnography Module Capno-S+
A side stream EtCO2 sensor, accurate and durable, suitable for various complex environments. Compatible with multiple protocols.
Understanding Capnography EtCO2 Module
Understanding Capnography EtCO2 Module

Understanding Capnography EtCO2 Module

Kingst's end-tidal carbon dioxide (ETCO2) modules are widely used in the operating room, ICU and emergency department, and can be used to monitor whether the position of the endotracheal intubation is correct, whether the spontaneous breathing is restored, whether the parameter settings during mechanical ventilation are reasonable, and whether the cardiopulmonary resuscitation is effective, etc. Kingst's products have the characteristics of quick response, high accuracy, good quality and stable performance.

Mainstream Vs Sidestream Capnography

ETCO2 Monitoring with mainstream VS side stream CO2 Sensors


Mainstream CO2 sensor

  • Judging the position of endotracheal intubation

  • On the patient'airway- quick response

  • There are neonatal, pediatric and adult adapters available


Side stream CO2 Sensor

  • Can be used for both intubated and non-intubated patients

  • The sensor is not directly connected in the ventilation circuit

  • Sampling without intubation,non-invasive monitoring

Specifications of Capnography EtCO2 Sensor


Environmental temperature5~50℃
Relative humidity10~90%(Non-condensing)
Atmospheric pressure55~115kpa
Power consumption150ma
Interface and communicationRS-232/ Standard E-8-1,38.4 kBaud,10 ms data interval (KM) Or customized according to customer requirements
Co2 Measuring range0-150mmHg
Accuracy0~40mmHg, inaccuracy≤± 2mmHg;
41~70mmHg, inaccuracy≤±5% of Reading;
70~100mmHg, inaccuracy≤± 8% of Reading;
101~150mmHg, inaccuracy≤±10% of Reading;
Respiration Rate2~150t/min
InaccuracyThe bigger value of ±1% or ±1t/min


Features of ETCO2 Module


ETCO2 module is essential monitoring tools in healthcare settings. They rely on an end tidal co2 sensor as the main component that enables health professionals to measure the carbon dioxide concentration at the end of a patient's breath. ETCO2 module is designed to be accurate, reliable, and adaptable to a variety of clinical settings.


One of the notable features of ETCO2 module is the use of capnography technology that provides continuous monitoring of patients' end-tidal CO2 levels. The capnography module ensures high-quality measurements and helps to detect possible respiratory complications, including hypoventilation or hyperventilation. Capnography detector allows real-time waveform monitoring and data transfer to electronic health records (EHRs).


The ETCO2 sensor included in the modules is highly sensitive and can detect small changes in carbon dioxide levels. This sensitivity ensures accurate results, especially during critical medical procedures such as anesthesia and mechanical ventilation.


Some ETCO2 module come with a calibration feature that allows for periodic calibrations to correct any calibration errors on the installed ETCO2 sensor. Regular calibrations allow the sensor to remain sensitive and reliable during patient care.


What is the use of Capnography EtCO2 Sensor?

ETCO2 monitoring is a non-invasive monitoring method that can reflect the state of pulmonary ventilation function and calculate the amount of carbon dioxide produced. In addition, it can also reflect the circulatory function. It has become a common clinical monitoring method. The ETCO2 Sensor is widely used in operating rooms, ICU and emergency departments. It can be used to monitor whether the position of the tracheal intubation is correct, whether the spontaneous breathing is restored, whether the parameter settings during mechanical ventilation are reasonable, and whether the cardiopulmonary resuscitation is effective, etc.

What is the use of Capnography EtCO2 Sensor?

FAQ of EtCO2 Modules

What is ETCO2 sensor?
What is ETCO2 sensor?

The high-precision infrared end-tidal CO2 module is designed based on the principle of infrared absorption spectroscopy to measure the CO2 concentration in exhaled air.

What is the operation principles of End Tidal CO2 Detector?
What is the operation principles of End Tidal CO2 Detector?

It is mainly based on that CO2 can absorb infrared rays with a wavelength of 4.26um, and the attenuation of infrared rays is proportional to the concentration of CO2.

How to clean and maintain EtCO2 Detector?
How to clean and maintain EtCO2 Detector?

Do not autoclave and do not immerse the sensor in liquid.

FAQ of EtCO2 Modules
